4-Wheel Diesel Forklift Truck

A robust 4-wheel diesel forklift, designed for heavy-duty material handling. Powered by a reliable diesel engine, it delivers strong lifting capacity and stable operation on various indoor and outdoor terrains. Easy to maneuver with 4-wheel configuration, suitable for warehouses, factories, construction sites, and logistics yards to lift and transport goods efficiently.
EMAIL INQUIRY

Model	-	CPCD20	CPCD25
Rated load	kg	2000	2500
Load center distance	mm	500	500
Power type	-	Diesel	Diesel
Wheel base	mm	1660	1660
Drive type	-	4×4	4×4
Lifting height(standard)	mm	3000	3000
Front tyre(mm)	-	7.00 - 12 - 12PR	7.00 - 12 - 12PR
Rear tyre(mm)	-	7.00 - 12 - 10PR	7.00 - 12 - 10PR
Free lift height	mm	167	167
Tilt angle(forward/backward)	°	6/12	6/12
Max. lifting height	mm	3170	3170
Overall height(with ROPS)	mm	2402	2402
Overall length(to fork face)	mm	3805	3805
Overall width(no sideshift)	mm	1890（1.8）	1890（1.8）
Fork length	mm	1070	1070
Fork outside width	mm	270	270
Turning radius(fork center)	mm	2490	2575
Ground clearance(min)	mm	210	240
Ground clearance of mast base	mm	110	110
Battery model	-	12 - 8DB480	12 - 8DB480
Lateral fork adjustment	mm	100/400	100/400
Travelling speed(unloaded/loaded)	km/h	17/15	17/15
Lifting speed(unloaded/loaded)	m/s	0.49/0.42	0.49/0.42
Lowering speed(unloaded/loaded)	m/s	0.42/0.36	0.42/0.36
Max. traction force(loaded)	N	2015	2615/2
Weight(standard)	kg	3488	3818
Axle load(unloaded, front tyre)	kg	1718/1712	1842/2108
Axle load(unloaded, rear tyre)	kg	1770/1776	1976/1710
Engine manufacturer	-	Xinchai	Xinchai
Engine model	-	4D27G31	4D35G31
Cylinder number		4	4
Engine displacement	L	2.71	3.505
Rated power	kW	36.8	48.5
Transmission type	-	1 - 1 1/2 7M	1 - 1 1/2 7M
Fuel tank capacity	L	60	60
Hydraulic system working pressure	Mpa	17.5	17.5
